A1A 100 TMF 100-1000 2p UL 2 Lug?Top
Product ID:93430
Updated: 2026/7/14
Key Features
- 1Achieve high interrupting ratings up to 10 kA at 240 V.
- 2Utilize thermal-magnetic trip units for precise current control.
- 3Simplify installation with DIN rail mounting for space efficiency.
- 4Ensure safety by meeting UL 489 and CSA C22.2 standards.
- 5Select the 2-pole configuration with top lugs for versatile applications.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Environmental Information | 1SDL000183R0001 9AKK108467A6707 | Product Net Width | 50.8 mm |
| Product Net Height | 60 mm | Product Net Depth / Length | 60 mm |
| Product Net Weight | 0.5 kg | Product Main Type | SACE FORMULA |
| Product Name | Moulded Case Circuit Breaker | Product Type | Automatic Circuit Breaker |
| Version | F | Number of Poles | 2P |
| Rated Current (In) | 100 A | Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | 690 V | Rated Operational Voltage | 240 V AC 250 V DC |
| Rated Uninterrupted Current (Iu) | 100 A | Release | TMF |
| Release Type | TM | Short-Circuit Performance Level | A |
| Standards | UL | Terminal Connection Type | Front for Copper-Aluminium Cables |
| Interrupting Rating acc. to UL489 | (240 V AC) 10 kA (250 V DC) 2 Poles in Series 5 kA | ETIM 8 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 | Manufacturer ID | 1SDA117234R1 |
Specifications may be subject to change without notice
