BCM/S16.1.3.1
Product ID:74161
Updated: 2026/7/15
Key Features
- 1Control 8 digital inputs and outputs precisely.
- 2Switch software-controlled 24VDC signals reliably.
- 3Utilize robust 0.5A transistor outputs.
- 4Connect easily via plug-in spring terminals.
- 5Integrate seamlessly as a BAC system extension.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Degree of Protection | IP20 | Data Sheet, Technical Information | 9AKK107046A7506 |
| Number of Outputs | 8 | Number of Digital Inputs | 8 |
| Number of Inputs | Analog (0 ... 10 V / 4 ... 20 mA) 8 | Product Range | KNX |
| Manual Operation | No | Number of Batteries | 0 |
| Product Net Width | 34 mm | Product Net Height | 135 mm |
| Product Net Depth / Length | 74 mm | Product Net Weight | 0.21 kg |
| ETIM 9 | EC001419 - PLC digital I/O-module | eClass | V11.0 : 27242204 |
| UNSPSC | 32151705 | Object Classification Code | A |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
| Manufacturer ID | 2CDG120065R0011 |
Specifications may be subject to change without notice
