BR-S 2/46/16H
Product ID:80500
Updated: 2026/7/15
Key Features
- 1Connect up to 46 circuits for enhanced electrical reliability.
- 2Construct robustly with durable materials for harsh environments.
- 3Comply with EU RoHS Directive 2011/65/EU and Amendment 2015/863.
- 4Apply in diverse industrial, commercial, and marine settings.
- 5Install easily without needing additional documentation.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Rated Operational Voltage | 400 V | Rated Conditional Short-Circuit Current (Inc) | 25 kA |
| Rated Uninterrupted Current (Iu) | 80 A | Pitch | 17.8 |
| Number of Poles | 2 | Number of Phases | 2 |
| Connection Type | Pin | Number of Batteries | 0 |
| Rated Cross-Section | 16 mm² | Width in Number of Modular Spacings | 46.0 |
| Product Net Width | 0.03 mm | Product Net Height | 0.015 mm |
| Product Net Depth / Length | 1016 mm | Product Net Weight | 0.241 kg |
| ETIM 8 | EC000215 - Phase busbar | ETIM 9 | EC000215 - Phase busbar |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Business |
| CN8 | 8538 90 99 | UNSPSC | 39121614 |
| eClass | V11.0 : 27142207 | Manufacturer ID | 2CDL824001R1646 |
Specifications may be subject to change without notice
