BW-A4.1-135
Product ID:77608
Updated: 2026/7/15
Key Features
- 1Monitor up to four distinct indoor/outdoor zones simultaneously.
- 2Automate free@home actuators using movement and ambient light data.
- 3Integrate a twilight sensor and temperature sensor for environmental control.
- 4Utilize a high-quality lens with an adjustable detection range.
- 5Benefit from built-in dismounting protection and interference suppression.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Ambient Air Temperature | Operation -25 ... +55 °C | Degree of Protection | IP55 |
| Function | Brightness sensor Temperature sensor | Number of Channels | 4 |
| Compatible Bus Systems | free@home (TP) | Product Range | free@home |
| Minimum Switching Time | Switch-On 10 second [unit of time] | Sensor Detection Range | 280 ° Frontal 16 m Lateral 16 m |
| Product Net Width | 110 mm | Product Net Height | 124.4 mm |
| Product Net Depth / Length | 157.75 mm | Product Net Weight | 294.3 g |
| ETIM 9 | EC001582 - Movement sensor for bus system | eClass | V11.0 : 27143144 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
| Manufacturer ID | 2CKA006220A0913 |
Specifications may be subject to change without notice
