CA5X-31M
Product ID:73617
Updated: 2026/4/3
Key Features
- 1Withstand 3600 cycles per hour for demanding industrial use. 2、Meet IEC 60947-5-1 standards for reliable 690V performance. 3、Suit AX06 to AX40 contactors for versatile applications. 4、Feature screw terminals for straightforward mounting. 5、Comply with CCC and CQC certificates for safety.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Net Width | 43 mm | Product Net Depth / Length | 32.5 mm |
| Product Net Height | 47 mm | Product Net Weight | 0.06 kg |
| Number of Auxiliary Contacts NO | 3 | Number of Auxiliary Contacts NC | 1 |
| Rated Operational Voltage | Auxiliary Circuit 690 V Main Circuit 690 V | Conventional Free-air Thermal Current (Ith) | acc. to IEC 60947-5-1, Π= 40 °C 16 A |
| Rated Operational Current AC-15 (Ie) | (690 V) 2 A (24 / 127 V) 6 A (220 / 240 V) 4 A (380 / 400 V) 3 A | Rated Short-time Withstand Current Low Voltage (Icw) | for 0.1 s 140 A for 1 s 100 A |
| Maximum Electrical Switching Frequency | (AC-15) 1200 cycles per hour (DC-13) 900 cycles per hour | Rated Operational Current DC-13 (Ie) | (24 V) 6 A / 144 W (110 V) 0.55 A / 60 W (125 V) 0.55 A / 69 W (220 V) 0.30 A / 66 W (250 V) 0.30 A / 75 W (400 V) 2.8 A / 134 W (500 V) 1 A / 72 W |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 690 V | Maximum Mechanical Switching Frequency | 3600 cycles per hour |
| Terminal Type | Screw Terminals | Suitable For | AX06 AX09 AX12 AX18 AX25 AX32 AX40 |
| Object Classification Code | K | ETIM 7 | EC000041 - Auxiliary contact block |
| ETIM 8 | EC000041 - Auxiliary contact block | ETIM 9 | EC000041 - Auxiliary contact block |
| eClass | V11.0 : 27371302 | UNSPSC | 39121500 |
| IDEA Granular Category Code (IGCC) | 4743 >> Auxiliary contact block | Manufacturer ID | 1SBN019040R1131 |
Specifications may be subject to change without notice
