ABBIntermediate relay
In Stock

CR-M230AC2L

Product ID:83532
Updated: 2026/4/3
ABB CR-M230AC2L

Key Features

  • 1Operate with a high-performance 230V AC control supply voltage. 2、Switch reliably with 250V/12A output contacts for circuit control. 3、Monitor status via an integrated LED for visual coil energization indication. 4、Test and lock contacts manually using the integrated orange button. 5、Install easily in compact spaces with durable 21.2x35.6x27.5mm design.
Product Details
CR-M230AC2L
ABB

Technical Specifications

Detailed engineering parameters

ParameterValueParameterValue
Product Net Width
21.2 mm
Product Net Height
35.6 mm
Product Net Depth / Length
27.5 mm
Product Net Weight
0.033 kg
Function
Pluggable miniature interface relay CR-M
Sub-Function
Relay with built in LED
Rated Control Supply Voltage (Us)
230 V AC
Rated Operational Voltage
250 V AC
Rated Frequency (f)
50 / 60 Hz
Output
2 c/o (SPDT) contacts
Output Signal
250 V / 12 A
Terminal Type
Flat-Pin Connections
Rated Operational Current AC-12 (Ie)
(230 V) 12 A
Rated Operational Current AC-15 (Ie)
(120 V) 3 A (230 V) 1.5 A
Rated Operational Current DC-12 (Ie)
(24 V) 12 A
Rated Operational Current DC-13 (Ie)
(24 V) 2.5 A (250 V) 0.1 A
Rated Insulation Voltage (Ui)
250 V
Degree of Protection
IP40
Mounting Position
1
Standards
CAN/CSA C22.2 No.14 IEC/EN 63000 IEC/EN 61810-1 UL 508
Maximum Operating Voltage UL/CSA
300 V AC
Pilot Duty UL/CSA
B300
Flammability According to UL94
HB
Ambient Air Temperature
Operation -40 ... +55 °C Storage -40 ... +85 °C
Maximum Operating Altitude Permissible
Without Derating 2000 m
Object Classification Code
K
ETIM 7
EC001437 - Switching relay
ETIM 8
EC001437 - Switching relay
ETIM 9
EC001437 - Switching relay
eClass
V11.0 : 27371601
UNSPSC
39122331
E-Number (Finland)
2712706
E-Number (Norway)
4187394
E-Number (Sweden)
4005336
Manufacturer ID
1SVR405611R3100

Specifications may be subject to change without notice
