CR-MX110DC4T
Product ID:93075
Updated: 2026/4/3
Key Features
- 1Isolate electrical signals reliably in demanding applications. 2、Ensure quality with a 1-year warranty and ISO9001 certification. 3、Select models with an integrated test button for manual actuation. 4、Integrate easily using versatile pluggable function modules. 5、Achieve long-lasting performance with cadmium-free contact material.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Net Width | 21.5 mm | Product Net Height | 37 mm |
| Product Net Depth / Length | 28 mm | Product Net Weight | 0.035 kg |
| Function | Pluggable miniature interface relay CR-MX | Rated Control Supply Voltage (Us) | 110 V DC |
| Rated Operational Voltage | 250 V AC | Output | 4 c/o (SPDT) contacts |
| Output Signal | 250 V / 5 A | Terminal Type | Flat-Pin Connections |
| Rated Operational Current AC-12 (Ie) | (230 V) 5 A | Rated Operational Current AC-15 (Ie) | (120 V) 1.9 A (230 V) 0.8 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 5 A | Rated Operational Current DC-13 (Ie) | (24 V) 1.8 A (120 V) 0.5 A |
| Rated Impulse Withstand Voltage (Uimp) | Between Coil and Contacts 1.5 kV | Rated Insulation Voltage (Ui) | 250 V |
| Degree of Protection | IP40 | Mounting Position | 1 |
| Standards | CSA 22.2 No. 14 IEC/EN 63000 IEC/EN 61010-1 UL 508 | Maximum Operating Voltage UL/CSA | 250 V AC |
| Flammability According to UL94 | V-2 | Ambient Air Temperature | Operation -40 ... +70 °C Storage -40 ... +70 °C |
| Maximum Operating Altitude Permissible | Without Derating 2000 m | Object Classification Code | K |
| ETIM 7 | EC001437 - Switching relay | ETIM 8 | EC001437 - Switching relay |
| ETIM 9 | EC001437 - Switching relay | eClass | V11.0 : 27371601 |
| UNSPSC | 39122331 | Manufacturer ID | 1SVR405643R8000 |
Specifications may be subject to change without notice
