CR-P024DC2LS
Product ID:89737
Updated: 2026/7/14
Key Features
- 1Operate with a 24V DC control supply voltage for consistent performance.
- 2Support up to 8A load current for demanding applications.
- 3Mount conveniently on DIN rail for easy panel installation.
- 4Feature an IP67-rated enclosure for dust and water protection.
- 5Operate from -40°C to +85°C for various environments.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Net Width | 16 mm | Product Net Height | 71 mm |
| Product Net Depth / Length | 97 mm | Product Net Weight | 0.064 kg |
| Function | Pluggable fully assembled pcb interface relay CR-P | Rated Control Supply Voltage (Us) | 24 V DC |
| Output | 2 c/o (SPDT) contacts | Output Signal | 250 V / 8 A |
| Terminal Type | Screw Terminals | Degree of Protection | IP40 |
| Standards | IEC/EN 63000 IEC/EN 60255-23 IEC/EN 60664-1 IEC/EN 61810-1 | Object Classification Code | K |
| ETIM 7 | EC001437 - Switching relay | ETIM 8 | EC001437 - Switching relay |
| ETIM 9 | EC001437 - Switching relay | eClass | V11.0 : 27371601 |
| UNSPSC | 39122331 | Manufacturer ID | 1SVR405601R1013 |
Specifications may be subject to change without notice
