CR-P024TRI1
Product ID:83484
Updated: 2026/7/15
Key Features
- 1Utilize high-quality cadmium-free contact material for increased lifespan.
- 2Control with 24V DC input and 3A/240V AC Triac output.
- 3Install in compact spaces with dimensions of 12.7x15.7x29 mm.
- 4Test manually using the integrated button for output contacts.
- 5Apply reliably in industrial machine and panel control.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Net Width | 12.7 mm | Product Net Height | 15.7 mm |
| Product Net Depth / Length | 29 mm | Product Net Weight | 0.011 kg |
| Function | Pluggable pcb optocoupler CR-P | Rated Control Supply Voltage (Us) | 10 ... 32 V DC |
| Output | TRIAC | Output Signal | 275VAC / 3A |
| Degree of Protection | IP67 | Standards | IEC/EN 62314 |
| Ambient Air Temperature | Operation -20 ... +50 °C Storage -20 ... +70 °C | ETIM 7 | EC001504 - Optocoupler |
| ETIM 8 | EC001504 - Optocoupler | ETIM 9 | EC001504 - Optocoupler |
| eClass | V11.0 : 27371604 | UNSPSC | 32111705 |
| Manufacturer ID | 1SVR405610R4070 |
Specifications may be subject to change without notice
