Key Features
- 1Track time with 0.01h reading accuracy for precise maintenance.
- 2Ensure durability with a robust design meeting EU RoHS standards.
- 3Install easily via DIN-Rail mounting for quick integration.
- 4Operate across a wide 230V/50Hz voltage range for versatility.
- 5Save panel space with a compact 85x17.5 mm footprint.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Rated Voltage (Ur) | 230 V AC | Voltage Range | 196 ... 264 V |
| Rated Frequency (f) | 50 / 60 Hz | Power Loss | 1.5 W |
| Accuracy | Reading Accuracy Class 0,01 h | Mounting Type | DIN-Rail |
| Environmental Information | 2CDU400019D0201 | Width in Number of Modular Spacings | 1.0 |
| Product Net Width | 17.5 mm | Product Net Height | 85 mm |
| Product Net Depth / Length | 58 mm | Product Net Weight | 0.05 kg |
| ETIM 8 | EC001641 - Hour meter | ETIM 9 | EC001641 - Hour meter |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
| CN8 | 9029 10 00 | eClass | V11.0 : 27142313 |
| Object Classification Code | P | Manufacturer ID | 2CDE100000R1601 |
Specifications may be subject to change without notice
