Key Features
- 1Track up to 100,000 hours with a 0.01-hour accuracy class. 2、Install easily on DIN rails with compact 85x58x17.5 mm dimensions. 3、Reduce energy consumption with low 1.5 W power loss. 4、Ensure compliance by meeting RoHS standards (EU 2011/65/EU). 5、Operate reliably in 240V AC, 60Hz industrial environments.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Rated Voltage (Ur) | 240 V AC | Rated Frequency (f) | 50 / 60 Hz |
| Power Loss | 1.5 W | Accuracy | Reading Accuracy Class 0,01 h |
| Environmental Information | 2CDU400019D0201 | Width in Number of Modular Spacings | 1.0 |
| Product Net Width | 17.5 mm | Product Net Height | 85 mm |
| Product Net Depth / Length | 58 mm | Product Net Weight | 0.05 kg |
| ETIM 8 | EC001641 - Hour meter | ETIM 9 | EC001641 - Hour meter |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
| CN8 | 9029 10 00 | eClass | V11.0 : 27142313 |
| Manufacturer ID | 2CDE100021R1601 |
Specifications may be subject to change without notice
