GSH202 AC S-D50/0.1
Product ID:68910
Updated: 2026/4/3
Key Features
- 1Protect against electrical shocks and overcurrents with 100 mA sensitivity. 2、Support demanding 50A industrial applications reliably. 3、Ensure safe tripping performance during fault conditions. 4、Integrate easily into systems at just 0.394 kg. 5、Rely on ABB's quality for automation solutions.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Standards | IEC 61009 GB 16917 | Tripping Characteristic | D |
| Type of Residual Current | Type AC | Rated Operational Voltage | 230 V AC |
| Rated Current (In) | 50 A | Rated Residual Current | 100 mA |
| Rated Short-Circuit Capacity | 6 kA | Maximum Breaking Capacity | 6 kA |
| Number of Protected Poles | 2 | Number of Poles | 2 |
| Number of Earth Leakage Circuit Breakers (ELCBs) | 1 | Operating Characteristic | Selective |
| Release Type | D | Short-Circuit Current Rating (SCCR) | 100 mA |
| Product Net Width | 70 mm | Product Net Height | 0.093 m |
| Product Net Depth / Length | 69 mm | Product Net Weight | 0.394 kg |
| ETIM 8 | EC002281 - Distributor assembly with combination RCCB/MCB | ETIM 9 | EC002281 - Distributor assembly with combination RCCB/MCB |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
| CN8 | 85363010 | eClass | V11.0 : 27400618 |
| Object Classification Code | F | Manufacturer ID | 2TAZ222203R3501 |
Specifications may be subject to change without notice
