OS125GD22LR-MNS
Product ID:74394
Updated: 2026/7/14
Key Features
- 1Deliver air circuit-breakers up to 6300A without derating.
- 2Adapt fully to needs with top/bottom cable or bus duct configurations.
- 3Ensure personnel safety with IEC 61641 internal arc testing.
- 4Reduce footprint via multilevel layout and minimize repair time.
- 5Meet global market standards including IEC 61439-1/-2 and CEI.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Net Weight | 2.6 kg | Fuse Size | NH000 NH00 |
| Fuse System | DIN | Mounting Type | Base mounting |
| Number of Poles | 4 | Operating Mode | Front Operated |
| Rated Operational Voltage | Main Circuit 690 V AC | Standards | IEC 60947-3 |
| Terminal Type | Lug terminals | Tightening Torque | 15 ... 22 N·m |
| Tightening Torque | 15 ... 22 N·m | ETIM 8 | EC001040 - Fuse switch disconnector |
| ETIM 9 | EC001040 - Fuse switch disconnector | UNSPSC | 39122233 |
| IDEA Granular Category Code (IGCC) | 5291 >> Fuse switch disconnector | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Manufacturer ID | 1SCA129777R1001 |
Specifications may be subject to change without notice
