OT25ETMM3TE22
Product ID:90262
Updated: 2026/7/14
Key Features
- 1Operate reliably at 690V AC for industrial power.
- 2Provide IP65 protection against dust and water.
- 3Mount flexibly with front or side operation options.
- 4Construct with high-impact, chemical-resistant plastic.
- 5Secure and maintain easily with a padlockable handle.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Degree of Protection | acc. to IEC 60529 IP65 | Product Net Width | 150 mm |
| Product Net Height | 200 mm | Product Net Depth / Length | 100 mm |
| Product Net Weight | 1.86 kg | Cable Cross-Section | 1.5 ... 35 mm² |
| Cable Entry Position | Up/Down | Cable Outlets Per Side | 2xø32.5+ø16.5 / 2xø32.5+ø16.5 |
| Connecting Capacity Main Circuit | Screw Clamp 1.5â¦35 mm² Screw Clamp / PE Terminal 2pcs, 1.5...25 mm² | Conventional Thermal Current (Ithe) | Fully Enclosed 63 A |
| Degree of Protection | acc. to IEC 60529 IP65 | Enclosure Material | Steel sheet |
| Handle Color | Black | Handle Type | Selector handle |
| Maximum Mounted Auxiliary Contacts | 2 NO, 1 NC | Mounted Auxiliary Contacts | 2 NO, 2 NC |
| Number of Poles | 3P | Power Loss | at Rated Operating Conditions per Pole 2.8 W |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 750 V | Rated Operational Current AC-22A (Ie) | (380 ... 415 V) 45 A (500 V) 45 A (690 V) 45 A |
| Rated Operational Current AC-23A (Ie) | (380 ... 415 V) 30 A (500 V) 30 A (690 V) 20 A | Rated Operational Power AC-23A (Pe) | (380 ... 415 V) 15 kW (500 V) 15 kW (690 V) 15 kW |
| Rated Operational Voltage | Main Circuit 750 V | Rated Short-Circuit Making Capacity (Icm) | (690 V AC) 1.4 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 1 kA | Special Functions | EMC |
| Standards | IEC 60947-1, -3 | ETIM 8 | EC000216 - Switch disconnector |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | Manufacturer ID | 1SCA140725R1001 |
Specifications may be subject to change without notice
