OT63ETPP4A
Product ID:70167
Updated: 2026/7/14
Key Features
- 1Ensure reliable isolation with high-performance, compact design.
- 2Simplify installation using versatile snap-on or screw-mounted options.
- 3Cover applications from 63 to 400 amperes with one product line.
- 4Meet global safety standards including IEC and UL/CSA.
- 5Customize operations with optional handles and auxiliary contacts.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Degree of Protection | acc. to IEC 60529 IP65 | Product Net Width | 248 mm |
| Product Net Height | 365 mm | Product Net Depth / Length | 217 mm |
| Product Net Weight | 4.5 kg | Cable Cross-Section | 10 ... 70 mm² |
| Cable Entry Position | Up/Down | Cable Outlets Per Side | 2xø37+ø18,6 / 2xø37+ø18,6 |
| Conventional Thermal Current (Ithe) | Fully Enclosed 115 A | Degree of Protection | acc. to IEC 60529 IP65 |
| Enclosure Material | Steel sheet | Handle Color | Red / Yellow |
| Handle Type | Selector handle | Maximum Mounted Auxiliary Contacts | 2 NO, 2 NC |
| Mounted Auxiliary Contacts | 1 NO, 0 NC | Number of Poles | 4 |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 750 V | Rated Operational Current AC-22A (Ie) | (380 ... 415 V) 63 A (500 V) 63 A (690 V) 63 A |
| Rated Operational Current AC-23A (Ie) | (380 ... 415 V) 63 A (500 V) 50 A (690 V) 35 A | Rated Operational Power AC-23A (Pe) | (380 ... 415 V) 30 kW (500 V) 30 kW (690 V) 30 kW |
| Rated Operational Voltage | Main Circuit 750 V | Special Functions | EMC |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | Manufacturer ID | 1SCA022439R9790 |
Specifications may be subject to change without notice
