OVR404 4L 40-440 P TS QS
Product ID:76460
Updated: 2026/4/3
Key Features
- 1Deliver high surge protection with 20 kA rated impulse current. 2、Ensure compliance with IEC/EN 61643-11 standards. 3、Mount easily on DIN rails for modular systems. 4、Support a wide voltage range of 400/690 V AC. 5、Integrate auxiliary NO + NC contacts for functionality.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Rated Voltage (Ur) | 240 ⦠415 V AC | Voltage Protection Level ( Up) | 1.5 kV (L-N) 1.5 kV (N-PE) 1.5 kV |
| Maximum Continuous Operating Voltage (Uc) | (L-PE) 275 V | Rated Service Short-Circuit Breaking Capacity (Ics) | 30 kA |
| Discharge Current | Nominal (8 / 20 µs) 20 kA I (max, 8 / 20 µs) 20 kA | Power Loss | 1 W |
| Number of Protected Poles | 4 | Transmission Standard | Mechanical |
| Mounting Type | Plug-In | Number of Batteries | 0 |
| Fuse Size | 1 modular spacing | Degree of Protection | IP20 |
| Environmental Information | 9AKK108467A9561 | Product Net Width | 72 mm |
| Product Net Height | 109 mm | Product Net Depth / Length | 90 mm |
| Product Net Weight | 450 g | ETIM 8 | EC002495 - Measurement device for surge protection |
| ETIM 9 | EC002495 - Measurement device for surge protection | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer | CN8 | 85369080 |
| eClass | V11.0 : 27201114 | Object Classification Code | F |
| Manufacturer ID | 2CCF606000A0003 |
Specifications may be subject to change without notice
