OVR T2 1N 40-150 P U
Product ID:69496
Updated: 2026/7/14
Key Features
- 1Protect against surges with 20 kA nominal and 40 kA max discharge current.
- 2Integrate easily into modular DIN rail systems for flexibility.
- 3Meet safety standards IEC 61643-1 and UL 1449 for compliance.
- 4Ensure long-term reliability with a design life of up to 20 years.
- 5Install simply in sub-distribution boards near equipment.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Standards | UL 1449 Ed3 | Suitable For | To protect the systems against the transient overvoltage (lightning) |
| Rated Voltage (Ur) | 120 V AC | Nominal AC Voltage of the System (Uo) | 120 V |
| Voltage Protection Level ( Up) | 1.2 kV (L-N) 1.2 kV (N-PE) 1.2 kV | Maximum Continuous Operating Voltage (Uc) | (L-PE) 175 V |
| Rated Service Short-Circuit Breaking Capacity (Ics) | 100 kA | Discharge Current | Nominal (8 / 20 µs) 20 kA I (max, 8 / 20 µs) 40 kA |
| Short Circuit Withstand Icc | 100 kA | Arrester Class | II |
| Number of Protected Poles | 2 | Number of Poles | 2 |
| Number of Conductors | 2 | Position of Neutral Terminals | Right |
| Transmission Standard | Optic | Version | Plug-in |
| Mounting Type | DIN-Rail | Options Provided | Residential, commercial building. |
| Preventive Maintenance Feature | No | Status Indicator | Yes |
| Fuse Size | 2 modular spacing | Degree of Protection | IP20 |
| Maximum Operating Altitude Permissible | Without Derating 5000 | Maximum Continuous Operating Voltage UL/CSA (MCOV) | (L-PE) 175 V (L-L) - V (L-N) 175 V (N-PE) 175 V |
| Maximum Operating Voltage UL/CSA | 175 V | Short-Circuit Current Rating (SCCR) | 200 kA |
| Type of Low Voltage Distribution System UL/CSA | Single Phase | Width in Number of Modular Spacings | 2 |
| Product Net Width | 35.6 mm | Product Net Height | 90.5 mm |
| Product Net Depth / Length | 64.8 mm | Product Net Weight | 0.24 kg |
| ETIM 8 | EC000941 - Surge protection device for power supply systems | ETIM 9 | EC000941 - Surge protection device for power supply systems |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Business |
| CN8 | 85363090 | eClass | V11.0 : 27130805 |
| Object Classification Code | 141DBC | Manufacturer ID | 2CTB802342R2000 |
Specifications may be subject to change without notice
