S201M-C63UC V
Product ID:68723
Updated: 2026/4/3
Key Features
- 1Provide reliable 10 kA short-circuit interruption. 2、Suit both AC and DC applications for versatile use. 3、Meet IEC/EN 60898-1 and 60947-2 international standards. 4、Feature a patented terminal for safe and simple wiring. 5、Utilize high-quality, recyclable thermoplastics.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Tripping Characteristic | C | Rated Current (In) | 63 A |
| Number of Poles | 1 | Product Net Width | 17.5 mm |
| Product Net Height | 85 mm | Product Net Depth / Length | 69 mm |
| Product Net Weight | 0.125 kg | ETIM 8 | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 9 | EC000042 - Miniature circuit breaker (MCB) | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Business | CN8 | 8536200000 |
| eClass | V11.0 : 27141901 | Object Classification Code | F |
| Manufacturer ID | 2TAZ113100R0634 |
Specifications may be subject to change without notice
