XT2V 160 Ekip Touch LSI In=100A 4p F F
Product ID:93101
Updated: 2026/4/3
Key Features
- 1Deliver 200kA breaking capacity for robust short-circuit protection. 2、Provide precise LSI protection with advanced electronic trip units. 3、Ensure long-term reliability with 25,000 mechanical operations. 4、Meet global safety standards including IEC 60947-1 and 60947-2. 5、Simplify installation with fixed mount design for easy integration.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Environmental Information | 9AKK108467A6707 | Product Net Width | 120.0 mm |
| Product Net Height | 130 mm | Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 1.6 kg | Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker | Product Type | Automatic Circuit Breaker |
| Version | F | Current Type | AC |
| Electrical Durability | 8000 cycle 120 cycles per hour | Mechanical Durability | 25000 cycle 240 cycles per hour |
| Number of Poles | 4P | Power Loss | at Rated Operating Conditions per Pole 4.2 W |
| Rated Current (In) | 100 A | Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V | Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 200 kA (230 V AC) 200 kA (240 V AC) 200 kA (380 V AC) 150 kA (415 V AC) 150 kA (440 V AC) 150 kA (500 V AC) 70 kA (525 V AC) 50 kA (690 V AC) 20 kA | Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 200 kA (230 V AC) 200 kA (240 V AC) 200 kA (380 V AC) 150 kA (415 V AC) 150 kA (440 V AC) 150 kA (500 V AC) 70 kA (525 V AC) 50 kA (690 V AC) 20 kA |
| Rated Uninterrupted Current (Iu) | 160 A | Release | Ekip Touch LSI |
| Release Type | EL | Short-Circuit Performance Level | V |
| Standards | IEC60947-2 GB/T 14028.2 | Sub-type | XT2 |
| Terminal Connection Type | Front | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Manufacturer ID | 2TFN000116A1001 |
Specifications may be subject to change without notice
