XT4N 160 Ekip M Touch LRIU In=100A 3p F F
Product ID:70331
Updated: 2026/4/3
Key Features
- 1Equip with Ekip M Touch LRIU for enhanced motor protection. 2、Achieve high breaking capacity of 65 kA at 240V AC. 3、Meet IEC 60947-2 standards for durability and compliance. 4、Install easily in compact spaces with DIN rail mounting. 5、Swap trip units for power, motor, or generator protection.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Environmental Information | 9AKK108467A6707 | Product Net Width | 105.0 mm |
| Product Net Height | 160.0 mm | Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 2.5 kg | Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker | Product Type | Automatic Circuit Breaker |
| Version | F | Current Type | AC |
| Electrical Durability | 8000 cycle 120 cycles per hour | Mechanical Durability | 25000 cycle 240 cycles per hour |
| Number of Poles | 3P | Power Loss | at Rated Operating Conditions per Pole 3.5 W |
| Rated Current (In) | 100 A | Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V | Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 65 kA (230 V AC) 65 kA (240 V AC) 65 kA (380 V AC) 36 kA (415 V AC) 36 kA (440 V AC) 36 kA (500 V AC) 30 kA (525 V AC) 20 kA (690 V AC) 10 kA | Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 65 kA (230 V AC) 65 kA (240 V AC) 65 kA (380 V AC) 36 kA (415 V AC) 36 kA (440 V AC) 36 kA (500 V AC) 30 kA (525 V AC) 20 kA (690 V AC) 10 kA |
| Rated Uninterrupted Current (Iu) | 160 A | Release | Ekip M Touch LRIU |
| Release Type | EL | Short-Circuit Performance Level | N |
| Standards | IEC60947-2 GB/T 14028.2 | Sub-type | XT4 |
| Terminal Connection Type | Front | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Manufacturer ID | 2TFN001194A1001 |
Specifications may be subject to change without notice
