CHV2-20
Product ID:51113
Updated: 2026/7/14
Key Features
- 1Completely stops reverse flow of fluids like compressed air.
- 2Available in a range of port sizes from Rc1/8 to Rc11/2.
- 3Designed for easy separation and recycling, reducing environmental impact.
- 4Downsized body with an average volume ratio of 34% and mass ratio of 25%.
- 5Includes fluoro-elastomer and oil-free specifications, with mounting brackets for small bore sizes.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model No. | CHV2 | Port size | 20 : Rc 3/4 |
| Option : Fluoro rubber | Blank: No option | Option : Oil-prohibited | Blank: No option |
| Accessory | Blank: None | A | 42mm |
| B | 95mm | φ C | 47mm |
| D | -mm | E | - |
| F | -mm | G | -mm |
| H | -mm | I | -mm |
| J | -mm | φ K | -mm |
| L | -mm |
Specifications may be subject to change without notice
