GWFY8-10
Product ID:50422
Updated: 2026/7/14
Key Features
- 1Compact size for space-saving in pneumatic piping systems.
- 2Flame-resistant white body for safe working environments.
- 3Smooth insertion and secure sealing with V-shaped packing seal.
- 4Freely rotating elbow union for easy piping and removal work.
- 5Food-grade lubricant oil used to eliminate pollution concerns in food manufacturing.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | GWFY8-10 | Applicable tube O.D.∅ | 8mm |
| M | R3/8 | H | 17mm |
| L1 | 35.0mm | L2 | 29.0mm |
| A | 12.0mm | B | 19.0mm |
| C | 14.5mm | D | 30mm |
| E | 4.2mm | F | 15.5mm |
| G | 26.5mm | N | 18.0mm |
| P | 15.5mm | Min. bore size | 6.0mm |
| Effective sectional area | 23.0mm^2 |
Specifications may be subject to change without notice
