GWJL3-6-L
Product ID:52021
Updated: 2026/7/14
Key Features
- 1Compact size for space-saving applications.
- 2Flame-resistant white body for safe use in various environments.
- 3V-shaped packing seal ensures smooth insertion and accurate sealing.
- 4Freely rotating elbow union simplifies piping and removal work.
- 5Standard sealant applied on thread part reduces work hours and ensures an even seal.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model No. | GWJL3-6-L | Compatible tube O.D. φ | 3.2mm |
| Thread | R1/8 | Hex | 10mm |
| L1 | 30.0mm | L2 | 15.5mm |
| A | 8.0mm | B | 12.5mm |
| C | 8.5mm | Min. bore size | 2.2mm |
| Eff. X-sectional area | 2.3mm^2 | Weight | 13.0g |
Specifications may be subject to change without notice
