GWTR10-0
Product ID:52089
Updated: 2026/4/3
Key Features
- 1Compact size for space-saving applications.
- 2Flame-resistant white body for safe working environments.
- 3V-shaped packing seal ensures smooth insertion and accurate sealing.
- 4Freely rotating elbow union simplifies piping and removal work.
- 5Easy tubing removal with push ring for quick and secure disconnection.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | GWTR10-0 | Applicable tube O.D.∅ | 10mm |
| L | 27.5mm | B | 21.5mm |
| C | 17.5mm | E | 4.2mm |
| F | 18.5mm | N | 13.0mm |
| Min. bore size | 8.0mm | Effective sectional area | 29.5mm^2 |
Specifications may be subject to change without notice
