JSG-40-CB
Product ID:51312
Updated: 2026/7/14
Key Features
- 1Reliable Durability: The JSG-40-CB tie rod cylinder with brake boasts a robust design and reliable brake mechanism, ensuring consistent performance.
- 2Powerful Holding Force: Equipped with a proprietary locking mechanism, it achieves a strong holding force equivalent to twice the thrust at 0.4 MPa working pressure.
- 3Medium Bore Size Series: Available in various bore sizes (φ40, φ50, φ63, φ80, φ100) to suit diverse applications.
- 4Compact and Reliable Brake: The brake mechanism is based on the well-established JSC3 Series, maintaining reliable durability and performance.
- 5Versatile Applications: Suitable for safety industries, with detailed documentation and CAD files available for easy integration into your projects.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Type | JSG | Bore size | 40mm |
| CD | 10mm | CE | 11mm |
| CF | 9mm | CI | 14mm |
| CV | 28mm | CW | 14mm |
Specifications may be subject to change without notice
