MJT6-8
Product ID:52161
Updated: 2026/7/14
Key Features
- 1The MJT6-8 is made from flame-resistant materials, ensuring safety in high-temperature environments.
- 2This tubing maintains flexibility, making it suitable for use in narrow spaces without compromising performance.
- 3Easy to install with push-in joint technology, reducing assembly time and effort.
- 4Comes with standard sealant application for R screw, ensuring a secure and leak-free connection.
- 5Incorporates PP resin to increase corrosion resistance, extending the lifespan of the tubing in harsh industrial conditions.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | MJT6-8 | Compatible tube O.D. | 6 |
| Port size | R1/4 | H | 12mm |
| L1 | 20mm | L2 | 20.5mm |
| A | 11mm | B | 11.5mm |
| Min. bore | 4.5 | Eff. X-sectional area | 14.4mm^2 |
| Weight | 34g |
Specifications may be subject to change without notice
