S1-B2-63
Product ID:52586
Updated: 2026/7/14
Key Features
- 1Achieve precise control with an index precision of ±30 seconds and repeatability of ±5 seconds.
- 2Built with robust materials, ensuring long-lasting performance in demanding environments.
- 3Suitable for a wide range of industrial applications, including manufacturing, automation, and more.
- 4Equipped with a high-resolution resolver (540672 P/rev) and motor insulation class F for reliable operation.
- 5Operates within a broad ambient temperature range (0 to 45°C) and humidity range (20 to 85% RH).
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | S1-B2-63 | Applicable bore size | 63mm |
| C | 9mm | CD | 14mm |
| CF | 37mm | CI | 24mm |
| CV | 40mm | CW | 20mm |
| D | 14mm | F | 10mm |
| G | 6.5mm | K | 80mm |
| MR | 16mm | SD | 59.0mm |
| WEIGHT | 0.62kg |
Specifications may be subject to change without notice
