SCG-B3-50
Product ID:51315
Updated: 2026/7/14
Key Features
- 1Customize the stroke length from 25 to 150 mm to fit your specific needs.
- 2Ensure reliable performance with double-acting operation, suitable for both forward and reverse movements.
- 3Choose from various mounting options, including head side trunnion and rod side trunnion, for flexible installation.
- 4Withstand up to 1.6 MPa (230 psi) working pressure and 8.0 MPa (1160 psi) proof pressure.
- 5Select from air cushion or rubber cushion for optimal performance and durability.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model no. | SCG-B3-50 | Applicable bore size | 50, 63mm |
| C | 9.0mm | CD | 14mm |
| CF | 45mm | CQ | 20mm |
| D | 18mm | F | 8mm |
| G | 7mm | K | 81mm |
| KA | 53mm | KB | 28.0mm |
| MR | 14mm | SD | 60mm |
| SE | 30mm | WEIGHT | 0.45kg |
Specifications may be subject to change without notice
