SCWS-LB-20lb
Product ID:50307
Updated: 2026/7/14
Key Features
- 1Available in ø125, ø140, ø160, ø180, ø200, and ø250 mm for diverse industrial needs.
- 2Customizable stroke lengths from 50 to 2000 mm to fit specific application requirements.
- 3Built with heat-resistant materials (up to 120°C) and designed for low hydraulic and rubber scraper types.
- 4Compatible with axial foot, flange, eye bracket, clevis bracket, and trunnion types for flexible installation.
- 5Equipped with an air cushion for enhanced energy absorption and stability in operation.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Model | SCWS-LB-20 | Bore | 20 |
| AB | 7.0mm | AL | 22.0mm |
| AR | 8mm | AG | 45.0mm |
| TR | 22mm | E | 36mm |
| AT | 4mm | AH | 27.0mm |
| AO | 6.5mm | AU | 16mm |
| WF | 6mm | XA | 59mm |
| SA | 69mm | G | M5x16mm |
Specifications may be subject to change without notice
