AEVUZ-100-25-A-P-A
Product ID:511210
Updated: 2026/6/1
Key Features
- 1Operating mode: Single-acting / Pulling
- 2Piston diameter: 100 mm
- 3Theoretical force at 6 bar, forward stroke: 4222 N
- 4Stroke: 25 mm
- 5Cushioning: Elastic cushioning rings/pads at both ends
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Operating and pilot medium note | Can be operated with lubricated medium (subsequent lubrication required) | Operating medium | Compressed air in accordance with ISO 8573-1:2010 [7:4:4] |
| Operating pressure | 11.6 / 145 psi | Variant | Single-ended piston rod |
| Symbol | 00991204 | Position detection | Via proximity switch |
| Design feature | Piston diameter / Piston rod | Piston rod end | External thread |
| Operating mode | Single-acting / Pulling | Mounting position | Any |
| Cushioning | Elastic cushioning rings/pads at both ends | Piston rod thread | M20x1.5 |
| Piston diameter | 100 mm | Stroke | 25 mm |
Specifications may be subject to change without notice
