Key Features
- 1Support up to 5 valve positions for efficient system control. 2、Feature 3 x 1/4" NPT ports for secure pneumatic connections. 3、Ensure high durability with Festo's proven manufacturing quality. 4、Integrate seamlessly with the versatile Festo CPE component series. 5、Optimize compressed air distribution across various industrial applications.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width dimension | 16mm | Mounting position | Any |
| Max. no. of valve positions | 5 | Max. no. of pressure zones | 2 |
| Burst pressure | 725psi | Operating pressure | -0.9bar 10bar |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Temperature of medium | -5°C 50°C | Ambient temperature | -5°C 50°C |
| Max. tightening torque for valve mounting | 1.22Nm | Product weight | 272.869g |
| Manifold block type of mounting | With through-hole | Pneumatic valve mounting type | With internal thread |
| Pneumatic connection 1 | 1/4 NPT | Pneumatic connection 3 | 1/4 NPT |
| Pneumatic connection 5 | 1/4 NPT | Note on materials | RoHS-compliant |
| Manifold rail material | Wrought aluminum alloy | Manufacturer ID | 550073 |
Specifications may be subject to change without notice
