Key Features
- 1Support up to 2 valve positions for versatile pneumatic applications. 2、Operate with compressed air meeting ISO 8573-1:2010 standards. 3、Feature moderate corrosion resistance for industrial durability. 4、Ensure compliance with RoHS using PA-reinforced material. 5、Offer through-hole and H-rail mounting for easy installation.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Max. no. of valve positions | 2 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 85g |
| Sub-base mounting type | With through-hole With H-rail | Pneumatic connection 1 | G3/8 |
| Note on materials | RoHS-compliant | Housing material | PA-reinforced |
| Manufacturer ID | 164967 |
Specifications may be subject to change without notice
