Key Features
- 1Ensure reliable operation in high-performance pneumatic applications. 2、Support up to 2 versatile valve positions for system control. 3、Withstand high-pressure conditions with a 3 MPa burst pressure rating. 4、Construct with RoHS-compliant, PA-reinforced housing for durability. 5、Install flexibly using through-hole or H-rail mounting options.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Max. no. of valve positions | 2 | Burst pressure | 232psi |
| Operating pressure | -0.09MPa 1MPa | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 950g |
| Sub-base mounting type | With through-hole With H-rail | Pneumatic connection 1 | G3/8 |
| Note on materials | RoHS-compliant | Housing material | PA-reinforced |
| Manufacturer ID | 164965 |
Specifications may be subject to change without notice
