Key Features
- 1Support up to 3 valve positions for precise pneumatic control. 2、Ensure reliable operation meeting ISO 8573-1:2010 compressed air standards. 3、Construct with PA-reinforced materials for durability and corrosion resistance. 4、Operate in lubricated mode to enhance system longevity and performance. 5、Weigh only 225 grams as a compact, RoHS-compliant industrial solution.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Max. no. of valve positions | 3 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 225g |
| Sub-base mounting type | With through-hole With H-rail | Pneumatic connection 1 | G1/2 |
| Note on materials | RoHS-compliant | Housing material | PA-reinforced |
| Manufacturer ID | 187825 |
Specifications may be subject to change without notice
