crcn-m5-pk-2
Product ID:8059
Updated: 2026/4/4
Key Features
- 1Ensure secure pneumatic connections with the male M5 thread. 2、Fit tubing with a precise 3 mm outer diameter perfectly. 3、Resist corrosion using high-alloy stainless steel construction. 4、Prevent air leaks with the integrated sealing ring feature. 5、Operate versatilely from -0.95 to 10 bar pressure.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Nominal width | 1.5mm | Type of seal on screwed plug | Sealing ring |
| Pack size | 10 | Operating pressure for entire temperature range | -0.95bar 10bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
| For use in the food industry | See supplementary material information | Ambient temperature | 0°C 60°C |
| Product weight | 1.8g | Pneumatic connection 1 | External thread M5 |
| Pneumatic connection 2 | for pneumatic tubing outside diameter 3 mm | Note on materials | RoHS-compliant |
| Housing material | High-alloy stainless steel | Material of threaded seal | NBR High-alloy stainless steel |
| Manufacturer ID | 30985 |
Specifications may be subject to change without notice
