DZH-32-160-PPV-A
Product ID:510531
Updated: 2026/5/29
Key Features
- 1Operating mode: Double acting
- 2Piston diameter: 32 mm / equivalent diameter
- 3Theoretical force at 6 bar, return stroke: 415 N
- 4Theoretical force at 6 bar, forward stroke: 483 N
- 5Stroke: 160 mm
- 6Cushioning: Pneumatic cushioning, adjustable at both ends
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Operating and pilot medium notes | Can be operated with lubricated medium (subsequently must always be operated with lubricated medium) | Operating medium | Compressed air, conforming to ISO 8573-1:2010 [7:4:4] |
| Operating pressure | 0.6 / 10 bar | Torque/Guide protection | Elliptical piston |
| Variant | Single-ended piston rod | Symbol | 00991235 |
| Position detection | Via proximity switch | Design feature | Cylinder diameter / Piston rod |
| Operating mode | Double acting | Mounting position | Optional |
| Cushioning | Pneumatic cushioning, adjustable at both ends | Piston rod torsion backlash (+/-) | 1.7 deg |
| Piston rod thread | M10x1.25 | Piston diameter | 32 mm / equivalent diameter |
| Stroke | 160 mm |
Specifications may be subject to change without notice
