dzh-32- -ppv-a
Product ID:1552
Updated: 2026/7/5
Key Features
- 1Handle demanding applications with precision and reliability.
- 2Ensure precise flow regulation for optimal system performance.
- 3Offer long-lasting operation with minimal maintenance requirements.
- 4Integrate seamlessly into existing Festo pneumatic systems.
- 5Deliver consistent performance in manufacturing and robotics.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Stroke | 1mm 1000mm | Piston diameter | 32 mm Equivalent diameter |
| Max. angle of rotation of the piston rod +/- | 1.7deg | Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | Any | Mode of operation | Double-acting |
| Structural design | Piston Piston rod | Position sensing | For proximity sensor |
| Symbol | 00991235 | Protection against torsion/guide | Oval piston |
| Operating pressure | 0.6bar 10bar | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L | Ambient temperature | -20°C 80°C |
| Cushioning length | 19mm | Max. torque for protection against rotation | 1Nm |
| Theoretical force at 6 bar, retracting | 415N | Theoretical force at 6 bar, advancing | 483N |
| Additional weight per 10?mm stroke | 30g | Basic weight with 0?mm stroke | 500g |
| Type of mounting | Optionally: With internal thread With accessories | Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant | Cover material | Aluminum |
| Seals material | TPE-U(PU) | Housing material | Aluminum |
| Piston rod material | High-alloy steel | Manufacturer ID | 14040 |
Specifications may be subject to change without notice
