DZH-50- -PPV-A
Product ID:510546
Updated: 2026/5/29
Key Features
- 1Operating mode: Double acting
- 2Piston diameter: 50 mm / Equivalent diameter
- 3Theoretical force at 6 bar, forward stroke: 1178 N
- 4Stroke: 1 / 1000 mm
- 5Cushioning: Pneumatic cushioning, adjustable at both ends
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Piston rod material | High-alloy steel | Piston seal material | TPE-U(PU) |
| Housing material | Aluminium | Seal material | TPE-U(PU) |
| Cover material | Aluminium | Material note | RoHS compliant |
| Pneumatic connection | G1/4 | Mounting type | Mounting via internal thread / With accessories |
| Basic weight at 0 mm stroke | 1263 g | Additional weight per 10 m stroke | 52.3 g |
| Additional moving mass per 10 mm stroke | 24.2 g | Moving mass at 0 mm stroke | 431 g |
| Theoretical force at 6 bar, forward stroke | 1178 N | Theoretical force at 6 bar, return stroke | 989 N |
| Max. torque for anti-rotation protection | 1.7 Nm | Cushioning length | 23 mm |
| Ambient temperature | -20 / 80 °C | Paint-wetting impairment substances (PWIS) conformity | VDMA24364-B2-L |
| Corrosion resistance class CRC | 2 - Moderate corrosion resistance | Note on operating and pilot medium | Can be operated with lubricated medium (must then always be operated with lubricated medium) |
| Operating medium | Compressed air conforming to ISO 8573-1:2010 [7:4:4] | Operating pressure | 0.6 / 10 bar |
| Torque/Guide protection | Elliptical piston | Variant | Single-ended piston rod |
| Symbol | 00991235 | Position detection | Via proximity switch |
| Design feature | Cylinder diameter / Piston rod | Operating mode | Double acting |
| Mounting position | Optional | Cushioning | Pneumatic cushioning, adjustable at both ends |
| Torsional play of piston rod (+/-) | 0.75 deg | Piston rod thread | M16x1.5 |
| Piston diameter | 50 mm / Equivalent diameter | Stroke | 1 / 1000 mm |
Specifications may be subject to change without notice
