esh-ha-2-pk
Product ID:6526
Updated: 2026/7/4
Key Features
- 1Maximize space with a compact 2mm nominal width design.
- 2Install vertically for versatile and easy mounting.
- 3Reduce corrosion stress with a corrosion resistance class of 1.
- 4Connect efficiently using the vacuum port on top.
- 5Ensure compliance and durability with RoHS-approved NBR and steel.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Nominal width | 2mm | Volume | 0.169cm3 |
| Mounting position | Any | Structural design | Vacuum connection at top |
| Classification of suction cup holder | Size 2 | Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-A1-L |
| Ambient temperature | -10°C 60°C | Product weight | 7g |
| Type of mounting | With lock nut | Suction cup mounting | Diameter 4 mm |
| Vacuum connection | PK-4 | Note on materials | RoHS-compliant |
| Seals material | NBR Steel | Retaining bracket material | Aluminum Brass, nickel-plated POM Tempered steel High-alloy steel |
| Manufacturer ID | 189196 |
Specifications may be subject to change without notice
