esh-ha-2-qs
Product ID:6525
Updated: 2026/4/3
Key Features
- 1Mount vertically with a compact 4mm suction cup design. 2、Construct robustly using NBR seals and multiple bracket materials. 3、Resist corrosion with CRC 1 rating for harsh environments. 4、Secure attachment via lock nut mounting for system stability. 5、Meet RoHS and VDMA24364-A1-L standards for compliance.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Nominal width | 2mm | Volume | 0.501cm3 |
| Mounting position | Any | Structural design | Vacuum connection at top |
| Classification of suction cup holder | Size 2 | Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-A1-L |
| Ambient temperature | 0°C 60°C | Product weight | 12g |
| Type of mounting | With lock nut | Suction cup mounting | Diameter 4 mm |
| Vacuum connection | QS-6 | Note on materials | RoHS-compliant |
| Seals material | NBR | Retaining bracket material | Aluminum Brass, nickel-plated POM Tempered steel High-alloy steel |
| Manufacturer ID | 189195 |
Specifications may be subject to change without notice
