esh-hb-6-g
Product ID:6542
Updated: 2026/7/4
Key Features
- 1Choose from 6 holder sizes and 8 types for flexibility.
- 2Construct with high-alloy steel and POM for durability.
- 3Operate reliably from -10°C to +60°C.
- 4Ensure low corrosion with RoHS and CRC Class 1.
- 5Install easily via internal thread and side port.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Nominal width | 10mm | Volume | 7.25cm3 |
| Mounting position | Any | Structural design | Vacuum connection at side |
| Classification of suction cup holder | Size 6 | Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-A1-L |
| Ambient temperature | -10°C 60°C | Product weight | 271g |
| Type of mounting | With internal thread | Suction cup mounting | M20x2 |
| Vacuum connection | G1/4 | Note on materials | RoHS-compliant |
| Retaining bracket material | Aluminum Brass, nickel-plated POM Tempered steel High-alloy steel | Manufacturer ID | 189212 |
Specifications may be subject to change without notice
