ESNU-12- -P-A
Product ID:510572
Updated: 2026/5/29
Key Features
- 1Operating mode: Pushing / Single-acting
- 2Piston diameter: 12 mm
- 3Theoretical force at 6 bar, advancing stroke: 61 N
- 4Stroke: 1 / 50 mm
- 5Cushioning: Elastic cushioning rings/pads at both ends
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Cylinder barrel material | High-alloy stainless steel | Piston rod material | High-alloy stainless steel |
| Seal material | NBR / TPE-U(PU) | Cover material | Wrought aluminum alloy / Clear anodized |
| Material note | RoHS compliant | Pneumatic connection | M5 |
| Mounting type | With accessories | Additional weight per 10 m stroke | 4 g |
| Basic weight for 0 mm stroke | 75 g | Additional moving mass per 10 mm stroke | 2 g |
| Moving mass for 0 mm stroke | 18.5 g | Theoretical force at 6 bar, advancing stroke | 61 N |
| Impact energy at end positions | 0.07 J | Ambient temperature | -20 / 80 °C |
| Paint-wetting impairment substances (PWIS) conformity | VDMA24364-B1/B2-L | Corrosion resistance class CRC | 2 - Moderate corrosion resistance |
| Note on operating and pilot medium | Can be operated with lubricated medium (must then continue to be operated with lubricated medium) | Operating medium | Compressed air, compliant with ISO 8573-1:2010 [7:4:4] |
| Operating mode | Pushing / Single-acting | Operating pressure | 1.5 / 10 bar |
| Variant | Single-ended piston rod | Position detection | Via proximity switch |
| Design feature | Cylinder bore / Piston rod / Cylinder barrel | Piston rod end | External thread |
| Compliant with standard | ISO 6432 | Mounting position | Optional |
| Cushioning | Elastic cushioning rings/pads at both ends | Piston rod thread | M6 |
| Piston diameter | 12 mm | Stroke | 1 / 50 mm |
Specifications may be subject to change without notice
