esv-80-ss
Product ID:6922
Updated: 2026/7/4
Key Features
- 1Operate in a wide temperature range from -30°C to 180°C.
- 2Construct from durable, chemical-resistant silicone material.
- 3Choose between versatile round or flat mounting shapes.
- 4Connect securely via the standard M10 threaded pneumatic port.
- 5Meet food industry standards for safe processing environments.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Min. workpiece radius | 400mm | Suction cup diameter | 80mm |
| Suction cup volume | 19.312cm3 | Connection position | Top |
| Mounting position | Any | Symbol | 00991485 |
| Suction cup shape | Round, flat | Operating pressure | -13.775psi 0psi |
| Nominal operating pressure | -10.15psi | Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| LABS (PWIS) conformity | VDMA24364 zone III | For use in the food industry | See supplementary material information |
| Ambient temperature | -30°C 180°C | Holding force at nominal operating pressure | 309.7N |
| Product weight | 33g | Color | Transparent |
| Shore hardness | 50 +/- 5 | Note on materials | RoHS-compliant |
| Suction cup material | VMQ (silicone) | Manufacturer ID | 191005 |
Specifications may be subject to change without notice
