EZH-1,5/6,5-10
Product ID:510357
Updated: 2026/7/13
Key Features
- 1Operating mode: Push / Single-acting
- 2Piston diameter: 3 mm / Equivalent diameter
- 3Theoretical force at 6 bar, advancing stroke: 3.8 N
- 4Stroke: 10 mm
- 5Cushioning: No cushioning
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Piston rod material | Reinforced polyamide | Housing material | Aluminium |
| Seal material | NBR | Cover material | Aluminium |
| Pneumatic connection | Barbed fitting PK-3 | Mounting type | With transverse holes |
| Product weight | 4 g | Theoretical max. return force (spring) | 1.7 N |
| Theoretical min. return force (spring) | 1 N | Theoretical force at 6 bar, advancing stroke | 3.8 N |
| Ambient temperature | 0 / 60 °C | Paint-wetting impairment substance (PWIS) conformity | VDMA24364 Zone III |
| Corrosion resistance class CRC | 2 - Moderate corrosion resistance | Operating and pilot medium note | Can be operated with lubricated medium (must then always be operated with lubricated medium) |
| Operating medium | Compressed air conforming to ISO 8573-1:2010 [7:4:4] | Operating pressure | 3 / 6 bar |
| Torque / Guide protection | Rectangular piston rod | Symbol | 00991200 |
| Position detection | None | Design feature | Bore / Rectangular piston rod |
| Operating mode | Push / Single-acting | Mounting position | Optional |
| Cushioning | No cushioning | Piston diameter | 3 mm / Equivalent diameter |
| Stroke | 10 mm |
Specifications may be subject to change without notice
