Key Features
- 1Ensure reliable operation with a robust piston gate valve design. 2、Control manually for straightforward and easy operation. 3、Minimize wear using a soft sealing principle to extend lifespan. 4、Simplify applications where precise flow regulation is not required. 5、Integrate into high-quality Festo Classic series compressed air systems.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Structural design | Piston gate valve | Actuation type | Manual |
| Sealing principle | Soft | Exhaust air function | Without flow control option |
| Manual override | None | Symbol | 00995571 |
| Valve function | 3/2, bistable | Operating pressure | 0bar 16bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | Note on materials | RoHS-compliant |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Temperature of medium | -10°C 60°C |
| Ambient temperature | -10°C 60°C | Type of mounting | Line installation With accessories |
| Mounting position | Any | Flow direction | Non-reversible |
| Product weight | 192g | Pneumatic connection 3 | G1/8 |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas | Seals material | NBR |
| Housing material | Die-cast aluminum | Manufacturer ID | 170681 |
Specifications may be subject to change without notice
