Key Features
- 1Ensure 40 µm filtration for high-quality compressed air. 2、Reduce maintenance with a fully automatic condensate drain. 3、Integrate easily into pneumatic systems via in-line installation. 4、Remove impurities efficiently with a sintered filter and centrifugal separator. 5、Operate reliably within a 2 to 12 bar pressure range.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | Maxi | Series | D |
| Mounting position | Vertical +/- 5° | Grade of filtration | 40μm |
| Condensate drain | Fully automatic | Structural design | Sinter filter with centrifugal separator |
| Bowl guard | Metal bowl guard | Symbol | 00991520 |
| Operating pressure | 2bar 12bar | Standard nominal flow rate | 5300l/min |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:9:-] Inert gas | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Storage temperature | -10°C 60°C |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [7:8:4] Inert gas | Temperature of medium | 5°C 60°C |
| Ambient temperature | 5°C 60°C | Product weight | 1440g |
| Type of mounting | Line installation With accessories | Pneumatic connection 1 | G1 |
| Pneumatic connection 2 | G1 | Note on materials | RoHS-compliant |
| Compressed air filter material | PE | Housing material | Die-cast zinc |
| Material of bowl | PC | Manufacturer ID | 159619 |
Specifications may be subject to change without notice
