Key Features
- 1Ensure 5μm filtration for high-purity compressed air and gases.
- 2Minimize downtime with an automatic condensate drain system.
- 3Provide efficient operation using a sintered filter and centrifugal separator.
- 4Allow easy installation with vertical mounting (+/-5° angle).
- 5Meet stringent environmental standards with RoHS-compliant materials.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | Maxi | Series | D |
| Mounting position | Vertical +/- 5° | Grade of filtration | 5μm |
| Condensate drain | Manually rotating | Structural design | Sinter filter with centrifugal separator |
| Bowl guard | Metal bowl guard | Symbol | 00991519 |
| Operating pressure | 0bar 16.547bar | Standard nominal flow rate | 16461.86l/min |
| Operating medium | Compressed air as per ISO 8573-1:2010 [-:9:-] Inert gas | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Storage temperature | -10°C 60°C |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [6:8:4] Inert gas | Temperature of medium | -10°C 60°C |
| Ambient temperature | -10°C 60°C | Product weight | 1329.615g |
| Type of mounting | Line installation With accessories | Note on materials | RoHS-compliant |
| Compressed air filter material | PE | Housing material | Die-cast zinc |
| Material of bowl | PC | Manufacturer ID | 546466 |
Specifications may be subject to change without notice
