Key Features
- 1Achieve 99.9999% efficiency with 0.01 µm filtration. 2、Eliminate manual draining via fully automatic condensate drain. 3、Operate reliably within a 2 to 12 bar pressure range. 4、Withstand corrosion with die-cast zinc and borosilicate fiber construction. 5、Integrate easily with vertical mounting and in-line accessories.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Series | D | Size | Midi |
| Structural design | Fiber filter | Grade of filtration | 0.01μm |
| Condensate drain | Fully automatic | Symbol | 00991544 |
| Operating pressure | 2bar 12bar | Operating medium | Compressed air as per ISO 8573-1:2010 [6:8:4] Inert gas |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [1:7:2] Inert gas | Max. standard flow rate for air quality class | 740l/min |
| Min. standard flow rate for air quality class | 240l/min | Filter efficiency | 99.9999% |
| Bowl guard | Metal bowl guard | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Temperature of medium | 1.5°C 60°C |
| Ambient temperature | -10°C 60°C | Residual oil content | 0.01mg/m3 |
| Differential pressure display | Visual display | Type of mounting | Optionally: Line installation With accessories |
| Mounting position | Vertical +/- 5° | Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G? | Housing material | Die-cast zinc |
| Compressed air filter material | Borosilicate fiber | Material of bowl | PC |
| Note on materials | RoHS-compliant | Product weight | 834g |
| Manufacturer ID | 532856 |
Specifications may be subject to change without notice
