Key Features
- 1Deliver 0.01 µm filtration for supreme air purity and system reliability.
- 2Withstand moderate corrosion stress (Class 2 per Festo 940 070) in harsh environments.
- 3Feature a fully automatic condensate drain to boost efficiency and cut maintenance.
- 4Operate effectively within a 1 to 16 bar pressure range for versatile use.
- 5Utilize a die-cast zinc and borosilicate fiber construction for extreme durability.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Series | D | Size | Maxi |
| Structural design | Fiber filter | Grade of filtration | 0.01μm |
| Condensate drain | Fully automatic | Symbol | 00991520 |
| Operating pressure | 1.448bar 12.411bar | Operating medium | Compressed air as per ISO 8573-1:2010 [6:8:4] Inert gas |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [1:7:2] Inert gas | Filter efficiency | 99.9999% |
| Bowl guard | Metal bowl guard | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Temperature of medium | 1°C 60°C |
| Ambient temperature | -10°C 60°C | Residual oil content | 0.01mg/m3 |
| Type of mounting | Optionally: Line installation With accessories | Mounting position | Vertical +/- 5° |
| Housing material | Die-cast zinc | Compressed air filter material | Borosilicate fiber |
| Material of bowl | PC | Note on materials | RoHS-compliant |
| Product weight | 1190.7g | Manufacturer ID | 546449 |
Specifications may be subject to change without notice
