Key Features
- 1Achieve 99.9999% efficiency with 0.01 µm filtration.
- 2Fit into tight spaces with a compact mini design.
- 3Manually drain condensate via a rotary valve.
- 4Integrate easily using G1/8 pneumatic connections.
- 5Meet ISO8573-1:2010 compressed air quality standards.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | Mini | Series | D |
| Mounting position | Vertical +/- 5° | Grade of filtration | 0.01μm |
| Filter efficiency | 99.9999% | Condensate drain | Manually rotating |
| Structural design | Fiber filter | Max. condensate volume | 22ml |
| Bowl guard | Metal bowl guard | Symbol | 00991740 |
| Operating pressure | 1bar 16bar | Operating medium | Compressed air as per ISO 8573-1:2010 [6:8:4] Inert gas |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Air quality class at the output | Compressed air as per ISO 8573-1:2010 [1:7:2] Inert gas |
| Temperature of medium | 1.5°C 60°C | Residual oil content | 0.01mg/m3 |
| Ambient temperature | -10°C 60°C | Product weight | 500g |
| Type of mounting | Line installation With accessories | Pneumatic connection 1 | G1/8 |
| Pneumatic connection 2 | G1/8 | Note on materials | RoHS-compliant |
| Compressed air filter material | Borosilicate fiber | Housing material | Die-cast zinc |
| Material of bowl | PC | Manufacturer ID | 162658 |
Specifications may be subject to change without notice
